Self-cleaning Solar Street Light, Jsdsolar AL series
Automatic self-cleaning | IOT LoRa System | Mircrowave sensor
Key features
- Automatic Self-Cleaning: Daily cleaning of solar panels removes debris, maintaining optimal charging efficiency .
- IOT LoRa System: Enables wireless remote control and monitoring via computer, with 4G/3G/GPRS command transmission .
- Prismatic LiFePO4 Battery: Operates in 25℃–65℃, stops charging above 65℃, and offers 3,000 charge cycles for long lifespan .
- Intelligent Controls: Temperature control protects the battery, while lighting control adapts LED modes based on remaining battery capacity in bad weather .
- Adjustable Bracket: 180° rotatable bracket allows flexible installation for various environments .
SEND INQUIRY
Back to Product List
Intelligent Solar Lighting System With Automatic Cleaning Technology
The self cleaning solar street light combines solar power generation, automatic maintenance functions, and intelligent lighting control into one outdoor lighting solution. Designed for roads, public areas, and infrastructure projects, it helps maintain solar charging performance by automatically removing dust, debris, and surface contamination from the photovoltaic panel. This integrated design reduces manual maintenance requirements while supporting stable illumination in outdoor environments.
Smart Solar Street Light With IoT LoRa Remote Management
Outdoor lighting systems often operate across large areas where regular inspection can increase maintenance workload. The integrated cleaning mechanism works according to scheduled settings, helping keep the solar panel surface clear and improve energy collection consistency.
- Automatic solar panel cleaning to reduce dust accumulation
- IoT LoRa communication for remote monitoring and control
- LiFePO4 battery technology for stable energy storage
- Intelligent lighting adjustment based on environmental conditions
- IP66 protection for outdoor weather resistance
- Adjustable mounting structure for flexible installation angles
- Suitable for roads, parks, and public lighting projects
The remote management system allows operators to check lighting status, adjust operating modes, and monitor system conditions through connected platforms. This improves visibility into lighting performance without requiring frequent on-site inspection.
Solar LED Street Light With Intelligent Energy Management
Solar lighting performance depends on effective energy collection, storage capacity, and power distribution. The system combines high-efficiency LED lighting with intelligent control functions to manage energy usage according to different conditions.
The LiFePO4 battery supports stable charging and discharging performance across changing outdoor environments. Intelligent temperature and lighting control functions help regulate operation according to surrounding conditions, improving system adaptability.
The automatic cleaning function plays an important role in maintaining photovoltaic efficiency, especially in areas affected by dust, bird droppings, or airborne particles. By keeping the panel surface cleaner, the system can maintain better charging conditions throughout long-term outdoor operation.
Durable Outdoor Lighting Solution For Smart Infrastructure Projects
Outdoor lighting installations require equipment that can operate reliably under different weather conditions. The IP66-rated structure provides protection against water and dust exposure, supporting long-term operation in outdoor environments.
The adjustable bracket design allows flexible positioning during installation, helping optimize solar exposure and lighting coverage. Combined with intelligent control technology and durable components, the system provides a practical solution for modern solar lighting applications.
With automatic cleaning capability, remote monitoring functions, and reliable solar energy management, the self cleaning solar street light supports smart city lighting, roadway illumination, and outdoor infrastructure projects. JSDSolar provides lighting configuration support, control system planning, installation guidance, and customized solar lighting solutions.
Technical Data
| Technical Parameter | AL-X6 | AL-X8 | AL-X10 | AL-X12 |
|---|---|---|---|---|
| Solar Module | 60w/18v | 80w/18v | 100w/36v | 120w/36v |
| High Capacity Lithium Battery | 460.8Wh | 537.5Wh | 768Wh | 921.6Wh |
| LED qty | 180Pcs | 270Pcs | 360Pcs | 450Pcs |
| Mode/Luminous Flux (all light pattern) | L/M/T/U(Compound with photocell sensor, timing, dimming, microwavesensor, intelligent powel controlsaving) |
|||
| Working Mode | 5 Peak sun hours | |||
| Solar Panel Charge Time | 8 Sun hours | |||
| Working Time All Light Pattern | >=12hours | |||
| Working on Raining days backup | 3 days | |||
| Color Temperature | 6000K(Programed by qty) | |||
| Induction angle | 70°x 145° | |||
| Light Pole Diameter | 70mm | |||
| Storage Temperature | 0-55℃ | |||
| Operating Humidity | <=95%RH | |||
| Working Temperature(Charge) | 0-55℃ | |||
| Working Temperature(Discharge) | 10℃-60℃ | |||
| Ingress Protection | IP66 | |||
| Recommend Installation Height | 3-5m | 5-7m | 7-9m | 8-10m |
| Product Package Dimensions | 1175*500*145MM | 1600*500*145MM | 1870*500*145MM | 2085*500*145MM |
| Tailstock Gross Weight | 20.7kg | 26.9kg | 32.5kg | 37.2kg |
Common Questions
-
How do I select the appropriate model for my project's installation height and lighting requirements?
-
For installation heights of 3-10m, the AL series offers models with max lumens (10800LM-21600LM). Choose a higher wattage model (e.g., AL-X6 for 10800LM) for areas requiring stronger illumination. Refer to the technical parameters for detailed specifications .
-
What is the battery lifespan and warranty coverage for large-scale projects?
-
The LiFePO4 lithium batteries support over 2000 charge-discharge cycles and come with a 5-year warranty for 90% output power and a 25-year warranty for 80% output power, ensuring long-term reliability for project deployments .
-
Can the solar street lights integrate with smart city management systems for remote monitoring?
-
Yes, the optional IOT LoRa system supports GPRS/3G/4G connectivity, enabling real-time remote monitoring, fault alarms, and parameter adjustment via Google map integration. It allows unified management across large-scale projects without regional limitations .
-
What installation precautions should be taken to ensure optimal performance in project sites?
-
Ensure solar panels face true south in the Northern Hemisphere or north in the Southern Hemisphere. Avoid shading from structures/trees and prevent artificial light sources (e.g., advertising boards) from triggering day mode. Peel off the solar panel protective film to activate charging .
-
How does the system perform in extreme weather conditions, and what protection features are included?
-
The lights have an IP68 waterproof rating and operate in temperatures from -20°C to +60°C. The MPPT controller includes multiple protections (overcharge/over-discharge, short circuit, etc.), ensuring stability in harsh environments .
-
What technical support is available for large-scale project deployments and maintenance?
-
JSD Solar provides full digital MPPT control technology (tracking efficiency >99%) and intelligent charge-discharge management. For project-specific needs, contact our team for customized solutions and post-installation support .
